GetValueListForField

The GetValueListForField returns the values list for the specified field.

On this page

Usage

Privileges. This method requires Read privileges.

Parameters.

The parameters for the GetValueListForField method are described in the following table.

Parameter

Data Type

Value

sessionToken

String

Valid sessionToken returned by the general.CreateUserSession method.

fieldId

Integer

Internal ID of the Values List field.

Note: The ID of a field can be determined by reviewing the Application Detail Report from within Application Builder or by invoking the record.GetRecordById method and reviewing the mappings.

Output. This method returns a string. The value is an XML string containing all available values list items (ID, Value, and Description) in the values list. Second-level items are nested within the first-level SelectDefValue element. If there is a failure, the API issues an exception.

Samples

Sample C# Code

sValuesList = field.GetValueListForField(sSessionToken, 302);

Sample Request

The following is a sample SOAP 1.1 request and response. The placeholders shown would be replaced with actual values. SOAP 1.2 also is supported.

POST /archer/ws/field.asmx HTTP/1.1

Host: staging

Content-Type: text/xml; charset=utf-8

Content-Length: length

SOAPAction: "http://archer-tech.com/webservices/GetValueListForField"

<?xml version="1.0" encoding="utf-8"?>

<soap:Envelope xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">

    <soap:Body>

      <GetValueListForField xmlns="http://archer-tech.com/webservices/">

        <sessionToken>string</sessionToken>

        <fieldId>int</fieldId>

      </GetValueListForField>

    </soap:Body>

</soap:Envelope>

Sample Response

HTTP/1.1 200 OK

Content-Type: text/xml; charset=utf-8

Content-Length: length

<?xml version="1.0" encoding="utf-8"?>

<soap:Envelope xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/">

    <soap:Body>

      <GetValueListForFieldResponse xmlns="http://archer-tech.com/webservices/">

        <GetValueListForFieldResult>string</GetValueListForFieldResult>

      </GetValueListForFieldResponse>

    </soap:Body>

</soap:Envelope>

Sample String in the Response

<SelectDefValues>

    <SelectDefValue>

      <guid>d074d029-66b2-4631-b555-119e5ec3c274</guid>

      <Id>3156</Id>

      <Name>False</Name>

      <select_value_desc />

      <AssociativeFlag>false</AssociativeFlag>

      <select_value_color />

      <DefaultFlag>false</DefaultFlag>

    </SelectDefValue>

    <SelectDefValue>

      <guid>5b92db8d-dc94-430f-99bf-785d0ccaabf8</guid>

      <Id>3155</Id>

      <Name>True</Name>

      <select_value_desc />

      <AssociativeFlag>false</AssociativeFlag>

      <select_value_color />

      <DefaultFlag>false</DefaultFlag>

    </SelectDefValue>

</SelectDefValues>
